NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM - AR130SS

NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM

Model: AR130SS

NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SSNuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SSNuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SSNuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SSNuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SSNuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SS
NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SS
NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SS
NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SS
NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SS
NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SS
+1more

Color : Black

NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SS
Black
NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SS
Black
NuTone 30-Inch 4-Way Convertible Under-Cabinet Range Hood, 270 Max Blower CFM AR130SS
Black

Key Features

  • Perfect for replacement as well as new installations, this powerful 4-way convertible range hood will fit into most all applications. The enclosed light and fan/filter assembly makes for easier cleaning

  • The 4-way convertibility of this hood provides flexible installation for use in either ducted or non-ducted applications. Discrete recirculation louvers are hidden at the top of the hood, which helps to provide a smooth, clean appearance

  • With a powerful 270 Max Blower CFM, 2-speed fan, this range hood provides adequate capture for electric and most gas ranges

  • A specially designed lighting system allows the use of either a LED or halogen bulb up to 50 watts (bulb not provided)

  • Dishwasher-safe aluminum mesh filter (S99010467) provides highly efficient grease removal

  • ADA compliant, remote operation is possible using a standard UL approved wall switch (sold separately)

  • Optional 7 in. round BP87Q damper sold separately

  • Non-duct capable with use of charcoal filter (S97021380 in USA or HPFX1 in Canada), sold separately. Hidden ductless louvers on top of hood exhaust away from cabinetry.

Read More

Available from Southern Appliance, serving customers throughout Georgia.

Features
Specifications
Certifications

Features

Perfect for replacement as well as new installations, this powerful 4-way convertible range hood will fit into most all applications. The enclosed light and fan/filter assembly makes for easier cleaning

The 4-way convertibility of this hood provides flexible installation for use in either ducted or non-ducted applications. Discrete recirculation louvers are hidden at the top of the hood, which helps to provide a smooth, clean appearance

With a powerful 270 Max Blower CFM, 2-speed fan, this range hood provides adequate capture for electric and most gas ranges

A specially designed lighting system allows the use of either a LED or halogen bulb up to 50 watts (bulb not provided)

Dishwasher-safe aluminum mesh filter (S99010467) provides highly efficient grease removal

ADA compliant, remote operation is possible using a standard UL approved wall switch (sold separately)

Optional 7 in. round BP87Q damper sold separately

Non-duct capable with use of charcoal filter (S97021380 in USA or HPFX1 in Canada), sold separately. Hidden ductless louvers on top of hood exhaust away from cabinetry.

The 18” deep design provides 20% more coverage over the cooktop than the standard over-the-range microwave combination units

Range hood is installed as hardwired or with an optional power cord kit (HCK44; sold separately)

Certifications

HVI Certified certification

HVI Certified

UL Listed certification

UL Listed

Specifications

Product Details

Filter TypeAluminum
Heat Sentry™No
HVI CertifiedYes
Lighting TypeLED or Halogen
Sound Level (Sones)2
UL ListedYes
ADA ComplianceYes
Damper IncludedNo
ENERGY STAR® certifiedNo
Light Bulb Wattage50
Light Bulbs IncludedNo
Light Levels1
MaterialSteel
Nightlight Or Nighlight SettingNo
Ductless Recirculation CapableYes
Ductless Filter Or Kit IncludedNo
Remote Operation CapableNo
Speed Levels2
Switch Control TypeRotary
Rated Voltage120
Boost ModeNo
Country of OriginUnited States
Rated Amps1.3
Product Depth18"
Product Height6"
Product Width30"
Built-In TimerNo
CFM270 Max
Diameter7" Round
Vent TypeConvertible Built-In
Duct DirectionHorizontal/Vertical
Bulb (Recommended Type)GU10 or LED
Manufacturer Warranty1 Year

Dimensions & Weight

Width30 in.
Height6 in.
Length18 in.
Weight-

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width35 in.
Shipping Height11 in.
Shipping Length23 in.
Shipping Weight-
Total of Shipping Weight-
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement1.88 ft³
Dimensional Weight23.31 lbs.
Total of Cubes1.88 ft³
Total of Dimensional Weight23.31 lbs.
